Jackson 06401-003-80-83 Dishwasher Timer Kit W/wire Harnesses Screw Terminals Mounting Plate

CAD$2,113.07
In stock
SKU
06401-003-80-83
The Jackson 06401-003-80-83 Timer Kit serves as a replacement system for Jackson TempStar HH, LT, NB, S, SDS dishwashers to deliver accurate cycle duration for Highoperational performance. The kit contains wire harnesses alongside screws and terminals and a mounting plate and detailed installation instructions which simplify the installation process. The partprovides reliable accuracy to maintain wash cycles at consistent levels which results in operational efficiency and reduced delays. The included components form a secure connection that leads to reduced downtime and extended dishwasher life duration.
Manufacturer:

Dimensions

  • Length: 8.5 In
  • Width: 5.5 In
  • Height: 3 In
  • Weight: 1.9 lbs
https://partsfe.com/media/catalog/product/j/a/jackson-06401-003-80-83-dishwasher-timer-kit-w-wire-harnesses-screw-terminals-mounting-plate-88940-2.jpg

Product Notes

  • Comes With Wire Harnesses, Screw, Terminals, Mounting Plate
  • And Instructions
  • Jackson Tempstar (Hh, Lt, Nb, S, Sds)
JACKSON:
06401-003-80-83, 6401-003-80-83, 64010038083, JAC06401-003-80-83, JAC6401-003-80-83, JAC64010038083
Write Your Own Review
You're reviewing:Jackson 06401-003-80-83 Dishwasher Timer Kit W/wire Harnesses Screw Terminals Mounting Plate
Your Rating
Customer Questions
What Maintenance is required for the Jackson 06401-003-80-83 Timer Kit?

The Timer Kit should be kept free of moisture and grime inside the control panel. Regularly inspect the timer housing for loose wiring or mounting plate screws and ensure the wire harness connectors remain clean and seated.

How do I install the Jackson 06401-003-80-83 Timer Kit?

  • Disconnect power to the dishwasher and lock out service panel access.
  • Remove the old timer assembly and bracket from the control compartment. Note and tag all wire harness connections.
  • Install the mounting plate from the kit, attach the new timer module, and secure with screws provided.
  • Connect the wire harnesses and terminals according to the included instructions, referencing original wiring positions.
  • Restore power and run a test cycle to verify proper timing functions and that the unit advances correctly.

What are common issues with the Jackson 06401-003-80-83 Timer Kit?

Common problems include the machine failing to advance through wash/rinse cycles due to a faulty timer, burned fuse inside the timer kit, or loose/incorrectly connected wire harnesses causing no cycle initiation.

Which models of Jackson are compatible with the 06401-003-80-83 Timer Kit?

This timer kit fits the Dishmachine TempStar HH-E and TempStar HH-E VER models. It
