Waste King 103547 Ignition Module 25V 6-Second

Special Price CAD$510.76 Regular Price CAD$694.38

In stock

SKU

103547

The Waste King 103547 Ignition Module is an various component that enhances the operational efficiency of your disposal system. The 25V operating voltage of this module combines a 6-second lockout feature with a trial mechanism to protect your unit from overheating and excessive wear. The durable plastic construction makes this part compact with dimensions of 4" width and 5 3/16" height and 2" depth. The module provides 1/4" tab terminals for simple connection points and its screw centers are distributed at 3 5/16" intervals for easy installation.

Categories: Electrical & Hardware, Ignition Modules,

Manufacturer:

Waste King

Dimensions

Length: 5 In
Width: 4.5 In
Height: 2 In
Weight: 0.695 lbs

Product Notes

Color: Gray
Material: Plastic
Width: 4" | 102 mm
Height: 5 3/16" | 132 mm
Voltage: 25 V Ac
Amp: 0.2
Terminals: 1/4" Tab Terminals
Type: 6 Seconds Lockout And Trial
Depth: 2" | 51 mm
Screw Centers: 3 5/16" | 84 mm

Replaces Parts

ULTRAFRYER:

18-179, 18179, S87B1008, ULTR18179

Reviews

Write Your Own Review

FAQS

Customer Questions

What maintenance is required for the Waste King 103547 Ignition Module?

Ignition modules like the Waste King 103547 generally require periodic inspection for loose wiring, corrosion on terminals, and proper grounding. Keeping the surrounding area free from moisture and grease buildup maintain stable ignition performance.

How do I install the Waste King 103547 Ignition Module?

Disconnect power to the equipment and verify all circuits are off.
Remove the old ignition module and note all wire positions.
Mount the new Waste King 103547 module securely using the existing bracket or screw holes.
Connect wires to the corresponding terminals following the unit

What are common issues occur with the Waste King 103547 Ignition Module?

Common issues include weak or no spark due to worn terminals, improper grounding, or overheating from surrounding components.
