Hobart 116280-1 Convection Oven Temperature Controller W/Potentiometer 3/16" Shaft 150-450° Pitch 1/4" Male Tabs 7 EA
Special Price CAD$395.68 Regular Price CAD$551.62
Out of stock
SKU
116280-1
Manufacturer:
The Hobart 116280-1 Convection Oven Temperature Controller is electromechanical thermostat with an integrated potentiometer that regulates oven temperatures from 150F to 450F in compatible Hobart convection ovens. Installed behind the control panel it connects to the temperature sensing probe, heating circuit, and control knob through a 3/16" shaft with seven 1/4-inch male terminals. As the operator adjusts the temperature setting the controller receives input from the probe and cycles the heating elements or gas burners to maintain the selected cooking temperature. This interaction provides controlled heat regulation throughout the cooking process
Dimensions
- Length: 3.5 In
- Width: 2.7 In
- Height: 2.7 In
- Weight: 0.5 lbs
Product Notes
- Temp Controller W/ Potentiometer W/Slotted 3/16" D-Shaft,
- 150 To 450 Degree, 7Ea 1/4" Male Tabs,
- For Temp Probe Use #44-1235 Probe, Vulcan 353589-1.
- For Old Style Knob, Black 1-15/16" Dia, 3/16" D-Stem Flat
- Down, Has Pointer Arrow Use # 22-1597.
- For Pointer Knob W/ "D" Stem & Set Screw Use # 22-1107
- For Pointer Knob W/ 1/4: Hole & Set Screw Use # 22-1106
- Hobart Oven Cn85, Cn90
- Vulcan Oven Series Ert-10, Et-4
