Garland 4529434 Range Ignition Module Natural/LP Gas 24V

Be the first to review this product
Special Price CAD$212.33 Regular Price CAD$236.53
In stock
SKU
4529434
Add to Wish List
Electrical & Hardware, Power Supply/Power Cords, Shop by manufacturers
Manufacturer:

The Garland 4529434 Ignition module is an essential part of the equipment used in commercial Ranges, for natural and LP gas ranges. This module works at 24V and its function is to control the ignition of the gas burners through the transmission of electrical signals required for ignition of the burners with out causing any danger to the system. It guarantees proper ignition and at the same time reduces cases of accumulated or uncontrolled gas emission making the kitchen safer.

Dimensions

  • Length: 3.125 In
  • Width: 5.125 In
  • Height: 7 In
  • Weight: 0.62 lbs
https://partsfe.com/media/catalog/product/g/a/garland-4529434-range-ignition-control-box-natural-lp-gas-24v-23296-2.jpg

Product Notes

  • Black Baso Ignition Control Box.
  • Ign Module 24V, Nat/Lp Gas, ( Replaces Old # G770Mga-2 ),
  • 0 Sec Prepurge, 50 Sec Trial, No Retry, Inter-Purge 15 Sec.
  • Old Spark Post Ignition Cable Use # 38-1339
  • Includes Adaptor, Round Post To 1/4" Female Tab Term,
  • # 85-1071.
  • Garland Oven All Convection Ovens With Lp Gas & Electronic
  • Ignition. R280, Master Series, Cg-24R, Cg-36R, Cg-48R,
  • Cg-60R, Cg-72R, Eco-E-10, Eco-E-25, Gaw-24, Gaw-36, Gaw-48,
  • Gaw-60, Gaw-72, Ico-E-10, Ico-E-25, Mco-G-5 (Except
  • Foreign Units).
  • Us Range Oven Sdg-1, Sdg-2 Lp Units
Reviews
Write Your Own Review
You're reviewing:Garland 4529434 Range Ignition Module Natural/LP Gas 24V
Your Rating
FAQS
Customer Questions
No Questions
Shipping

We strive to provide our customers with a hassle-free and efficient shopping experience. Our shipping policy ensures the timely delivery of your orders and complete customer satisfaction. View More

Returns

We are committed to ensuring your complete satisfaction with every purchase. We understand that circumstances may arise where you must return a product or request a refund. If for any reason you are not satisfied, you may return the item(s) according to the terms outlined below. View More

Payment Methods

This Payment Policy outlines the terms and conditions governing all payments made for products purchased through our website. By making a purchase, you agree to be bound by this Payment Policy. View More

Installation Steps

Step1: Disconnect electrical power and shut off the range gas supply completely.

Step2: Open the control compartment to access the existing ignition box.

Step3: Carefully disconnect all wire harnesses and terminals.

Step4: Remove mounting screws securing the old unit.

Step5: Position the new ignition control box in the same location.

Step6: Reconnect wiring exactly as per the wiring diagram.

Step7: Secure the unit firmly with mounting hardware.

Step8: Restore power and gas, then verify proper ignition sequence.
