Lincoln 369393 Oven Ignition Control Module W/15-Sec Lockout 24V
Special Price CAD$377.38 Regular Price CAD$698.90
In stock
SKU
369393
Manufacturer:
The Lincoln 369393 Ignition Control Module Lockout is an electronic control unit for conveyor and impingement ovens for burner ignition and flame monitoring in commercial systems. It uses a 24V control circuit and starts the ignition process by switching on the ignition system and gas valve at the beginning of a heating cycle. The module will be placed in lockout if no flame is detected during the programmed 15-second secure window, which will prevent gas flow and unburned fuel buildup. It is used in oven systems in foodservice applications like restaurants. It is used in the appliance as a secure part and timing part that allows the appliance.
Dimensions
- Length: 5.3 In
- Width: 4 In
- Height: 2 In
- Weight: 1.1 lbs
Product Notes
- Ignition Control Module Currnet Style
- 24V, 15 Sec Lockout, 30 Sec P.P., Honeywell,
- 3-1/2" X 5-1/4"
- Grey Box Changed To Black Box 6/21/07
- Special Note: This Is The Ignition Control Module Only
- To Replace Existing Honeywell Module
- If Replacing Old Style Johnson
- Controls Modules G-60 Or G-65 Must Order Oem 369393 Ignition
- Control Kit And #441417 Transformer
- For Pilot Burner H1421, M-218, # 51-1380
- Lincoln Oven 1000 Thru 1005, 1040 Thru 1043, 1050, 1051,
- 1200, 1201, 1204, 1205, 1240 Thru 1243. 1450,1451,1480
