Vulcan Hart VH110841-1 Natural Gas Safety Bleed Gas Actuator W/ Pilot /4" FPT 300,000 BTU
Special Price CAD$400.25 Regular Price CAD$612.43
In stock
SKU
VH110841-1
The Vulcan Hart VH110841-1Natural Gas Safety Bleed Actuator 3/4" FPT with Pilot serves commercial cooking appliances by delivering safe and efficient gas flow regulation. This actuator controls natural gas supply through its 300,000 BTU output which connects through a 3/4" FPT connection to deliver reliable performance during applications such as fryers. The part includes a slotted thermopile magnet together with a bleed gas actuator featuring a 1/4" CCT pilot and 3/4" x 1/2" reducer bushings for straightforward installation and operational use.
Dimensions
- Length: 4.5 In
- Width: 2.5 In
- Height: 2.5 In
- Weight: 2.1 lbs
Product Notes
- [ Nat Gas ] [ Size 3/4" Fpt ] [ Nat Safety ][ 3.5"Wc ]
- [Bleed Gas Actuator] [ Width 4"] [ Brand Rsw ]
- 1/4" Cct Pilot Out Only, W/Slotted Thermopile Magnet
- 3/4" X 1/2" Reducer Bushings, Model 7000 Bmsgor
- Bleed Gas Ports 1/4" Cct, 300,000 Btu
- **Use # 51-1470 To Convert To Lp Gas.**
- Thermopile, H231, T-103, # 51-1122, Screw In Type, 3/8-32
- Brass Pile Holding Nut, 3/8-38 Thread For Magnet, 750Mv,
- 500Mv Under Load.
- Southbend Fryer Series: 14,18.
- Vulcan Hart Fryer 7891G, 7892G, Hf91G, Hf92G.
- Wolf Fryer Ss-Wtf-42, Wtf-42.
